ACS712

Features and Benefits:▪ Low-noise analog signal path▪ Device bandwidth is set via the new FILTER pin▪ 5 μs output rise time in response to step input current▪ 80 kHz bandwidth▪ Total output error 1.5% at TA = 25°C▪ Small footprint, low-profile SOIC8 package▪ 1.2 mΩ internal conductor resistance▪ 2.1 kVRMS minimum isolation voltage from pins 1-4 to pins 5-8▪ 5.0 V, single supply operation▪ 66 to 185 mV/A output sensitivity▪ Output voltage proportional to AC or DC currents▪ Factory-trimmed for accuracy▪ Extremely stable output offset voltage▪ Nearly zero magnetic hysteresis▪ Ratiometric output from supply voltage Description:The ACS712 provides economical and...
